What is runlevel in Linux?

RUNLEVELS: It is nothing but a mode of operation in Linux OS.

  • A  runlevel  is  a  software configuration of the system which allows only a selected group of processes to exist.
  • The processes spawned by init for each of these runlevels are defined in the /etc/inittab file.
  • Init can be in one of eight runlevels: 0-6 and S or s.  The runlevel is changed  by a privileged user running telinit command, which sends appropriate signals to init, telling it which runlevel to change to.



runlevel


  • Runlevels 0, 1, and 6 are reserved.
  • Runlevel 0 is used to halt the system, runlevel 6 is used to reboot the system, and runlevel 1 is used to get the system down into single user mode i.e into a state where administrative tasks can be performed; this is the default if neither the -h or -r flag is given to shutdown.
  • Runlevel 5 is full desktop mode with X sessions enabled providing graphical user interface.
  • Text based systems are defaulted to boot up with runlevel 3(Multiuser mode with network access).
  • Runlevel S is not really meant to be used directly, but more for the scripts that are executed when entering  runlevel 1.
  • Runlevels 7-9 are also valid, though not really documented. This is because "traditional" Unix variants don't use them.  In case you're curious, runlevels S and s are in fact the same.  Internally they are aliases for the same runlevel.

Runlevels and their meaning:

Runlevels System Configuration
0 System halt   (Do not use this for initdefault!)
1 Single user mode
2 Local multiuser without remote network (e.g. NFS)
3 Full multiuser with network
4 Not used
5 Full multiuser with network and xdm(Graphical mode with X session enabled.)
6 System reboot (Do not use this for initdefault!)

  • SHUDOWN does its job by signalling the init process, asking it to change the runlevel.
  • To see which actions are taken on halt or reboot see the appropriate entries for these runlevels in the file /etc/inittab.

 # The default runlevel of a system in which it will boot up is defined here in /etc/inittab file:

 20 id:3:initdefault:

To change the runlevel temporarily we can use init command. For eg. to change to runlevel 2 from 3, use:

localhost:>init 2

But again after system reboot the system will go the default runlevel i.e 3. To change runlevel permanently, edit the /etc/initab file and change the runlevel value in the above line.




  • To Check the current runlevel of the system

runlevel -- find the current and previous system runlevel.

localhost:>runlevel
N 3

Also you can use who -r to check runlevel of the system.

localhost:/sbin:>who -r
         run-level 3  2014-10-27 18:40                   last=S


  • To find what services and processes are running in a particular runlevel, we can use chkconfig command.

localhost:/etc:>chkconfig|more

SuSEfirewall2_init          off
SuSEfirewall2_setup      off
aaeventd                            off
acpid                                   on
apache2                             on
arpd                                   off


To get previous runlevel of the system

PREVLEVEL
              To get previous runlevel (It is useful after a runlevel switch is done).

 SYNOPSIS
       runlevel [utmp]

  • Runlevel reads the system utmp file (typically /var/run/utmp) to locate the runlevel record, and then prints the previous and current system runlevel on its standard output, separated by a single space.
  • If there is no previous system runlevel, the letter N will be printed instead.
  • If no utmp file exists, or if no runlevel record can be found, runlevel prints the word unknown and exits with an error.
  • Runlevel can be used in rc scripts as a substitute for the System-V who -r command.  However, in newer versions of init(8) this information  is  also available in the environment variables RUNLEVEL and PREVLEVEL.

More on runlevel: Booting

    After init is invoked as the last step of the kernel boot sequence, it looks for the file /etc/inittab to see if there is an entry of the type  initdefault  (see  inittab(5)).  The  initdefault  entry determines the initial runlevel of the system.  If there is no such entry (or no /etc/inittab at all), a runlevel must be entered at the system console.

       Runlevel S or s bring the system to single user mode and do not require an /etc/inittab file.  In single  user  mode,  /sbin/sulogin  is  invoked  on /dev/console.

       When  entering  single  user mode, init initializes the consoles stty settings to sane values. Clocal mode is set. Hardware speed and handshaking are not changed.

       When entering a multi-user mode for the first time, init performs the boot and bootwait entries to allow file systems to be mounted before users can log in.  Then all entries matching the runlevel are processed.
